Durable 5005 Aluminum Alloy Plate

The 5005 Aluminum Plate features a smooth surface finish that not only enhances its aesthetic appeal but also makes it easy to work with. Its excellent weldability and formability allow for seamless integration into various designs, making it a favorite among engineers and designers alike. Whether you’re constructing a sleek facade, creating custom signage, or fabricating components for machinery, the 5005 plate delivers the performance you need.
One of the standout characteristics of the 5005 Aluminum Plate is its ability to maintain its structural integrity in challenging environments. With a high resistance to oxidation and atmospheric corrosion, this aluminum plate is perfect for outdoor applications where exposure to the elements is a concern. Additionally, its lightweight nature reduces transportation costs and simplifies installation, making it a practical choice for any project.

product details

specification

Product Name	5005 Aluminum Plate
Width	20-3000mm or Customized	Thickness	0.1-120mm or Customized
Length	100-12000mm or Customized	Certificate	ISO, SGS, BV
Standard	JIS, AISI, ASTM, GB, DIN, EN, etc.
Brand	1000 Series: 1050, 1060, 1070, 1100, 1200, 1235, etc. 3000 Series: 3003, 3004, 3005, 3104, 3105, 3A21, etc. 5000 Series: 5005, 5052, 5083, 5086, 5154, 5182, 5251, 5754, 5A05, etc. 6000 Series: 6061, 6063, 6082, 6A02, etc. 7000 Series: 7050, 7475, 7075, etc. 8000 Series: 8A06, 8011, 8090, etc.
Surface	Coating, Embossing, Drawing, Polishing, Anodizing, etc.
OEM Service	Punching, Cutting Special Size, Making Flat Surface, Surface Treatment, etc.
Delivery Time	Received 30%, After deposit 7-15 working day
Application	Construction, Shipbuilding, Decoration, Industry, Manufacturing, Machinery, Hardware And Other Fields, etc.
Sample	Free Offers Sample
Packaging	Strapping, plastic bag, film, wooden pallet Standard seaworthy export packing or according to customer requirement

Product Display

Chemical Composition

Alloy

Others:

Each

Others:

Total

Al: Min.

5005

0.30

0.70

0.20

0.5~1.1

0.1

0.25

0.05

0.15

Margin

Mechanical Properties

Tensile Strength (MPa)	Test Stress (MPa)	Hardness HV	Elongation Rate （%）
160	145	46	11

Physical Performance

Density	Melting Point	Modulus of Elasticity	Thermal Conductivity	Resistance Rate
2.7 Kg/m³	655 °C	69.5 GPa	201W/m.K	0.033x10 ^-6 Ω.m

Annealing State

Brand	Annealing State
1xxx: 1050, 1050A, 1060, 1100	O, H12, H14, H16, H18, H22, H24, H26, H28, H111
3xxx: 3003, 3004, 3005, 3105	O, H12, H14, H16, H18, H22, H24, H26, H28, H111
5xxx: 5005, 5052, 5754, 5083, 5086, 5182, 5049, 5251, 5454	O, H22, H24, H26, H28, H32, H34, H36, H38, H111
6xxx: 6061, 6082	T4, T6, T451, T651
2xxx: 2024	T3, T351, T4
7xxx: 7075	T6, T651

Scope of Application

Aluminum Uses And Application Area
Food Packaging	Beverage can ends, cans, bottle caps, etc.
Building	Curtain walls, cladding, suspended ceilings, thermal insulation, venetian blinds, etc.
Transportation	Auto parts, passenger car bodies, aviation ships and air cargo containers.
Electronic Equipment	Electrical appliances, communication equipment,PCPlate drilling guide, lighting and heat dissipation materials, etc.
Consumer Goods	Umbrellas, cooking utensils, sports equipment, etc
Other	Military, color coated aluminum plate
